5406874-1 - TE Connectivity

5406874-1 Details

• Manufacturer Part Number:

  5406874-1

• Brand Name:

  AMP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  8 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  9

• Additional Feature:

  LOW PROFILE

• Board Mounting Option:

  BOARD LOCK

• Body Breadth:

  0.61 inch

• Body Length:

  3.32 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  D SUBMINIATURE CONNECTOR

• Contact Design:

  PREASSEM CONN

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  BELLOWED TYPE

• DIN Conformance:

  NO

• EMI Shielded:

  YES

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulator Color:

  BLACK

• Insulator Material:

  POLYESTER

• MIL Conformance:

  NO

• Mains Connector Rating:

  115/230VAC

• Mating Contact Pitch:

  0.085 inch

• Mating Contact Row Spacing:

  0.16 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  BAIL MOUNT

• Mounting Style:

  STRAIGHT

• Mounting Type:

  PANEL

• Number Of PCB Rows:

  2

• Number of Ports:

  1

• Number of Rows Loaded:

  2

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  4.064 mm

• Panel Mount:

  NO

• Plating Thickness:

  30u inch

• Shell Finish:

  NICKEL

• Shell Material:

  CARBON STEEL

• Shell Size:

  5/D

• Terminal Length:

  0.145 inch

• Terminal Pitch:

  2.16 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  50
