544BCJB002155BBG - Skyworks

544BCJB002155BBG Details

• Manufacturer Part Number:

  544BCJB002155BBG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Manufacturer:

  Skyworks Solutions Inc

• YTEOL:

  0

• Additional Feature:

  SUPPLY VOLTAGE 1.8V & 2.5V ALSO AVAILABLE; TRI-STATE; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  0.35 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  7%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Frequency-Max:

  800 MHz

• Operating Frequency-Min:

  0.2 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Output Load:

  100 OHM

• Package Equivalence Code:

  LCC8,.12X.2

• Physical Dimension:

  5.0mm x 3.2mm x 1.33mm

• Rise Time-Max:

  0.35 ns

• Screening Level:

  MIL-STD-883

• Supply Current-Max:

  111 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Nickel/Gold (Ni/Au)
