570BAB000383DG - Skyworks

570BAB000383DG Details

• Manufacturer Part Number:

  570BAB000383DG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Skyworks Solutions Inc

• YTEOL:

  6

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; DIFFERENTIAL OUTPUT

• Fall Time-Max:

  0.35 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Frequency-Max:

  1417.5 MHz

• Operating Frequency-Min:

  10 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Output Load:

  100 OHM

• Package Equivalence Code:

  LCC8,.2X.28,100

• Physical Dimension:

  7.0mm x 5.0mm x 1.8mm

• Qualification Status:

  Not Qualified

• Rise Time-Max:

  0.35 ns

• Screening Level:

  MIL-STD-883

• Supply Current-Max:

  108 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
