570BAB001614DG - Silicon Labs

Description: Programmable Oscillators Differential/single-ended; I2C programmable XO; 10-1417 MHz

Download 570BAB001614DG Model
Schematic symbol is unavailable for download
PCB footprint is unavailable for download
3D model is unavailable for download
PCB Footprints
570BAB001614DG - Silicon Labs PCB footprint - Other - Other - 570BAB001614DG-2
click to zoom
3D Models
570BAB001614DG - Silicon Labs  - 3D model - Other - 570BAB001614DG-2
click to zoom

570BAB001614DG Details

  • Manufacturer Part Number:


  • Rohs Code:


  • Part Life Cycle Code:


  • Reach Compliance Code:


  • Manufacturer:

    Silicon Laboratories Inc

  • Additional Feature:


  • Fall Time-Max:

    0.35 ns

  • Frequency Adjustment-Mechanical:


  • Frequency Stability:


  • JESD-609 Code:


  • Mounting Feature:


  • Operating Frequency-Nom:

    300 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Oscillator Type:


  • Output Load:

    100 OHM

  • Physical Dimension:

    7.0mm x 5.0mm x 1.8mm

  • Rise Time-Max:

    0.35 ns

  • Supply Voltage-Max:

    3.63 V

  • Supply Voltage-Min:

    2.97 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:


  • Symmetry-Max:

    55/45 %

  • Terminal Finish:

    Gold (Au) - with Nickel (Ni) barrier
