57LE-40360 - Solid Electric

57LE-40360 Details

• Manufacturer Part Number:

  57LE-40360

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Solid Electric Inc

• Body Breadth:

  0.61 inch

• Body Depth:

  0.594 inch

• Body Length:

  2.66 inch

• Body/Shell Style:

  PLUG

• Connector Type:

  OTHER D TYPE CONNECTOR

• Contact Finish Mating:

  AU ON NI

• Contact Gender:

  FEMALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  30 mΩ

• Contact Style:

  CENTRONIC

• Dielectric Withstanding Voltage:

  600VAC V

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  4.2926 mm

• Rated Current (Signal):

  3 A

• Shell Finish:

  TIN

• Shell Material:

  STEEL

• Terminal Length:

  0.19 inch

• Terminal Pitch:

  2.159 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  36
