5AGXMA5G6F35C6G - Intel

5AGXMA5G6F35C6G Details

• Manufacturer Part Number:

  5AGXMA5G6F35C6G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  FBGA-1152

• Country Of Origin:

  Mainland China, Malaysia, Taiwan, USA, Vietnam

• ECCN Code:

  3A991

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Intel Corporation

• YTEOL:

  7

• JESD-30 Code:

  S-PBGA-B1152

• Length:

  35 mm

• Number of CLBs:

  7170

• Number of Inputs:

  544

• Number of Logic Cells:

  190000

• Number of Outputs:

  544

• Number of Terminals:

  1152

• Operating Temperature-Max:

  85 °C

• Organization:

  7170 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HBGA

• Package Equivalence Code:

  BGA1152,34X34,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, HEAT SINK/SLUG

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  2.7 mm

• Supply Voltage-Max:

  1.13 V

• Supply Voltage-Min:

  1.07 V

• Supply Voltage-Nom:

  1.1 V

• Surface Mount:

  YES

• Technology:

  28 nm

• Temperature Grade:

  OTHER

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  35 mm
