5CGTFD7B5M15C7N - Intel

5CGTFD7B5M15C7N Details

• Manufacturer Part Number:

  5CGTFD7B5M15C7N

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  MBGA-484

• Country Of Origin:

  Mainland China, Malaysia, Taiwan, USA, Vietnam

• ECCN Code:

  3A991

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Intel Corporation

• YTEOL:

  8

• JESD-30 Code:

  S-PBGA-B484

• Length:

  15 mm

• Number of CLBs:

  5648

• Number of Inputs:

  240

• Number of Logic Cells:

  149500

• Number of Outputs:

  240

• Number of Terminals:

  484

• Operating Temperature-Max:

  85 °C

• Organization:

  5648 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFBGA

• Package Equivalence Code:

  BGA484,28X28,20

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, LOW PROFILE, FINE PITCH

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.25 mm

• Supply Voltage-Max:

  1.13 V

• Supply Voltage-Min:

  1.07 V

• Supply Voltage-Nom:

  1.1 V

• Surface Mount:

  YES

• Technology:

  CMOS, 28 nm

• Temperature Grade:

  OTHER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  15 mm
