5CGTFD9D5F27C7 - Intel

5CGTFD9D5F27C7 Details

• Manufacturer Part Number:

  5CGTFD9D5F27C7

• Part Life Cycle Code:

  Active

• Package Description:

  FBGA-672

• HTS Code:

  8542.31.00.60

• Manufacturer:

  Intel Corporation

• YTEOL:

  8

• JESD-30 Code:

  S-PBGA-B672

• Length:

  27 mm

• Number of Inputs:

  336

• Number of Logic Cells:

  301000

• Number of Outputs:

  336

• Number of Terminals:

  672

• Operating Temperature-Max:

  85 °C

• Organization:

  11356 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA672,26X26,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2 mm

• Supply Voltage-Max:

  1.13 V

• Supply Voltage-Min:

  1.07 V

• Supply Voltage-Nom:

  1.1 V

• Surface Mount:

  YES

• Technology:

  CMOS, 28 nm

• Temperature Grade:

  OTHER

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  27 mm
