6717 - Pomona Electronics

6717 Details

• Manufacturer Part Number:

  6717

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Pomona Electronics

• YTEOL:

  7.55

• Additional Feature:

  ROHS COMPLIANT, PANEL MOUNT

• Body Breadth:

  1.152 inch

• Body Depth:

  1.425 inch

• Body Length:

  0.567 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Finish Mating:

  GOLD

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  FEMALE

• Contact Material:

  BRASS

• Contact Resistance:

  3 mΩ

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• DIN Conformance:

  NO

• Durability:

  500 Cycles

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  WHITE

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mounting Option 1:

  GUIDE PIN

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number of Ports:

  2

• Operating Frequency-Max:

  4 GHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  YES

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.157 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  2

• VSWR:

  1.3
