712-5 - Teledyne Technologies

712-5 Details

• Manufacturer Part Number:

  712-5

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  9.1

• Body Height:

  6.99 mm

• Body Length or Diameter:

  8.51 mm

• Coil Current(DC)-Max:

  0.09 A

• Coil Operate Voltage(DC):

  3.6 V

• Coil Power:

  450 mW

• Coil Resistance:

  50 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .25A@115VAC

• Contact Current(AC)-Max:

  0.25 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@28VDC

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  1000000 Cycle(s)

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  4 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  3 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Switching Time:

  7 ms

• Termination Type:

  WIRE WRAP
