72T1895L4-4BBG - Renesas Electronics

72T1895L4-4BBG Details

• Manufacturer Part Number:

  72T1895L4-4BBG

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.71

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Access Time-Max:

  3.4 ns

• Additional Feature:

  ALTERNATIVE MEMORY WIDTH 9; ASYNCHRONOUS OPERATION ALSO POSSIBLE

• Clock Frequency-Max (fCLK):

  225 MHz

• Cycle Time:

  4.44 ns

• JESD-30 Code:

  S-PBGA-B144

• Length:

  13 mm

• Memory Density:

  1179648 bit

• Memory IC Type:

  OTHER FIFO

• Memory Width:

  18

• Number of Functions:

  1

• Number of Terminals:

  144

• Number of Words:

  65536 words

• Number of Words Code:

  64000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  64KX18

• Output Characteristics:

  3-STATE

• Output Enable:

  YES

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA144,12X12,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Parallel/Serial:

  PARALLEL

• Standby Current-Max:

  0.05 A

• Supply Current-Max:

  0.06 mA

• Supply Voltage-Max (Vsup):

  2.625 V

• Supply Voltage-Min (Vsup):

  2.375 V

• Supply Voltage-Nom (Vsup):

  2.5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  13 mm
