734-406/001-000 - Wago

Description: THT double-deck male header; 1.0 x 1.0 mm solder pin; angled; 100% protected against mismating; Pin spacing 3.5 mm; 12-pole

Download 734-406/001-000 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
734-406/001-000 - Wago - PCB symbol
click to zoom
PCB Footprints
734-406/001-000 - Wago PCB footprint - Other - Other - 734-406/001-000-2
click to zoom
3D Models
734-406/001-000 - Wago - 3D model - Other - 734-406/001-000-2
click to zoom

734-406/001-000 Details

  • Manufacturer Part Number:

    734-406/001-000

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Germany

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Manufacturer:

    WAGO Innovative Connections

  • YTEOL:

    7.95

  • Additional Feature:

    STANDARD: UL94V-0, PA66: SAFETY APPROVAL: KEUR

  • Fastening Method:

    CONNECTOR

  • Mounting Type:

    BOARD

  • Number of Decks:

    2

  • Number of Rows:

    2

  • Number of Ways:

    12

  • Rated Current:

    10 A

  • Rated Voltage:

    300 V

  • Safety Approval:

    ABS;CCA;CSA;EN;IEC;KEMA;UL

  • Terminal and Terminal Block Type:

    STRIP TERMINAL BLOCK

734-406/001-000 Frequently Asked Questions (FAQs)

  • The recommended torque for tightening the 734-406/001-000 connector is 0.6 Nm to 1.2 Nm, as specified in the WAGO installation instructions.
  • Yes, the 734-406/001-000 connector is suitable for outdoor use, as it has a IP67 rating, which means it is protected against dust and water ingress.
  • Yes, the 734-406/001-000 connector is designed to withstand high-vibration applications, with a vibration resistance of 10 g according to IEC 60068-2-6.
  • The operating temperature range of the 734-406/001-000 connector is -40°C to 125°C, making it suitable for use in a wide range of industrial and automotive applications.
  • Yes, the 734-406/001-000 connector is part of the WAGO TOPJOB S family of connectors, which are designed to be compatible with other WAGO products, including terminal blocks and connectors.
