73403-5120 - Molex

73403-5120 Details

• Manufacturer Part Number:

  73403-5120

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Molex

• YTEOL:

  8

• Body Breadth:

  0.451 inch

• Body Depth:

  0.822 inch

• Body Length:

  0.295 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF SMB CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  MALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• Dielectric Withstanding Voltage:

  1000VAC V

• Durability:

  50 Cycles

• Filter Feature:

  NO

• Insertion Loss:

  0.245 dB

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  6 GHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Shell Finish:

  FRONT-NICKEL AND REAR-TIN

• Shell Material:

  BRASS

• Terminal Length:

  0.104 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.29
