736-208 - Wago

Description: Double-deck PCB terminal block; 2.5 mm²; Pin spacing 5 mm; 16-pole; CAGE CLAMP®

Download 736-208 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
736-208 - Wago - PCB symbol
click to zoom
PCB Footprints
736-208 - Wago PCB footprint - Other - Other - 736-208-1
click to zoom
3D Models
736-208 - Wago - 3D model - Other - 736-208-1
click to zoom

736-208 Details

  • Manufacturer Part Number:

    736-208

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Poland

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Manufacturer:

    WAGO Innovative Connections

  • YTEOL:

    5.68

  • Additional Feature:

    FRONT ENTRY, CAGE CLAMP

  • Fastening Method:

    SOLDER

  • Mounting Type:

    BOARD

  • Number of Decks:

    2

  • Number of Rows:

    2

  • Number of Ways:

    16

  • Rated Current:

    10 A

  • Rated Voltage:

    300 V

  • Safety Approval:

    UL

  • Terminal and Terminal Block Type:

    MODULAR TERMINAL BLOCK

  • Wire Cross Section:

    2.5 mm2

  • Wire Gauge:

    12 AWG

736-208 Frequently Asked Questions (FAQs)

  • The recommended torque for screw terminals on the 736-208 connector is 0.6 Nm to 0.8 Nm (5.3 in-lbs to 7.1 in-lbs).
  • Yes, the 736-208 connector is designed to withstand high-vibration environments. It meets the vibration requirements of IEC 61373 Cat. 1, Class B, and EN 50155.
  • Yes, the 736-208 connector is suitable for outdoor use. It has a rating of IP67, which means it is protected against dust and water ingress, and can operate in temperatures ranging from -40°C to 85°C (-40°F to 185°F).
  • Yes, the 736-208 connector is designed to accept stranded wire. However, it's recommended to use a wire with a minimum strand count of 30 and a maximum outer diameter of 2.5 mm (0.098 in).
  • The maximum operating current for the 736-208 connector is 32 A per pole, with a maximum total current of 64 A for the entire connector.
