74VHCV574FT - Toshiba

Description: Flip Flops X34 OCTAL SCHMITT D-TYPE

Download 74VHCV574FT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
74VHCV574FT - Toshiba PCB footprint - Small Outline Packages - Small Outline Packages - TSSOP20B
click to zoom
3D Models
74VHCV574FT - Toshiba  - 3D model - Small Outline Packages - TSSOP20B
click to zoom

74VHCV574FT Details

  • Manufacturer Part Number:

    74VHCV574FT

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    TSSOP-20

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    7

  • Family:

    AHC/VHC/H/U/V

  • JESD-30 Code:

    R-PDSO-G20

  • Length:

    6.5 mm

  • Logic IC Type:

    BUS DRIVER

  • Number of Bits:

    8

  • Number of Functions:

    1

  • Number of Ports:

    2

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Characteristics:

    3-STATE

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Propagation Delay (tpd):

    23 ns

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    1.8 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    4.4 mm

74VHCV574FT Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the 74VHCV574FT is 3.0V to 5.5V.
  • It is recommended to power up the VCC pin before the input signals, and power down the VCC pin after the input signals. This ensures that the device is properly initialized and avoids any potential latch-up or damage.
  • The maximum clock frequency that the 74VHCV574FT can handle is 200 MHz.
  • The 74VHCV574FT requires proper termination to ensure signal integrity. It is recommended to use a 50-ohm termination resistor at the output of each buffer, and to ensure that the output is properly loaded to prevent signal reflection.
  • Yes, the 74VHCV574FT is compatible with 3.3V systems. However, it is recommended to ensure that the input signals are within the specified voltage range (VCC-0.5V to VCC+0.5V) to ensure proper operation.
