800-10-003-10-007000 - Mill-Max

800-10-003-10-007000 Details

• Manufacturer Part Number:

  800-10-003-10-007000

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.90.40.00

• Manufacturer:

  Mill-Max Mfg Corp

• YTEOL:

  10

• Body Depth:

  0.11 inch

• Body Length:

  0.3 inch

• Body/Shell Style:

  SOCKET

• Connector Type:

  BOARD CONNECTOR

• Contact Design:

  STAMPED

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  Gold (Au) - with Nickel (Ni) barrier

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  1000VAC V

• Filter Feature:

  NO

• Insulation Resistance:

  10000000000 Ω

• Insulator Material:

  POLYETHYLENE

• JESD-609 Code:

  e4

• Mating Contact Pitch:

  0.1 inch

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Type:

  CABLE

• Number Of Connectors:

  ONE

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Packing Method:

  BOX; TUBE

• Plating Thickness:

  10u inch

• Terminal Length:

  0.165 inch

• Terminal Pitch:

  2.54 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  3

• Wire Size-Max:

  18 AWG

• Wire Size-Min:

  20 AWG
