805-110 - Wago

805-110 Frequently Asked Questions (FAQs)

• What is the recommended torque for tightening the screws on the 805-110 connector?
  The recommended torque is 0.6 Nm to 1.2 Nm (5.3 in-lbs to 10.6 in-lbs) for the screws on the 805-110 connector.
• Can I use the 805-110 connector in high-vibration applications?
  Yes, the 805-110 connector is designed to withstand high-vibration environments. It meets the vibration requirements of IEC 60068-2-6 and can withstand vibrations up to 10 g (98 m/s²) in the frequency range of 10 Hz to 2000 Hz.
• Is the 805-110 connector suitable for use in harsh environments, such as those with high temperatures or humidity?
  Yes, the 805-110 connector is designed for use in harsh environments. It has an operating temperature range of -40°C to 125°C (-40°F to 257°F) and can withstand humidity up to 95% RH.
• Can I use the 805-110 connector with wire sizes other than the recommended AWG 20-14?
  While the 805-110 connector is designed for use with AWG 20-14 wires, it can be used with other wire sizes. However, the user must ensure that the wire size is compatible with the connector's current rating and that the wire is properly terminated to prevent damage to the connector or the wire.
• Is the 805-110 connector UL (Underwriters Laboratories) certified?
  Yes, the 805-110 connector is UL certified and meets the requirements of UL 310, the standard for connectors and switches for use in the United States.
