80HCPS1432CHMH footprint, schematic symbol and 3D model by Renesas Electronics

80HCPS1432CHMH - Renesas Electronics

Description: The IDT CPS-1432 is an 8x4/14x2/14x1 RapidIO Gen2 switch ideal for boards that require up to eight high bandwidth connections of up to 20 Gbps per port (8x4). The CPS-1432 can also be used in space constrained applications such as AMC or 6U/3U VPX where a large number of x4 links are used and small footprint is required. The CPS-1432 features a full, non-blocking bandwidth of 160 Gbps for up to 14 ports. It can also be used to drive backplanes or can be used as a backplane switch for small systems. The CPS-

Download 80HCPS1432CHMH Model

Schematic
symbols

PCB
footprints

3D
models

Symbol

click to zoom

PCB Footprints

80HCPS1432CHMH - Renesas Electronics PCB footprint - BGA - BGA - HMH576

click to zoom

3D Models

80HCPS1432CHMH - Renesas Electronics - 3D model - BGA - HMH576

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for 80HCPS1432CHMH
Part Number 80HCPS1432CHMH
Manufacturer Renesas Electronics
Pin Count 576
Part Category Integrated Circuit
Package Category BGA
Footprint Name BGA - HMH576
Released Date Feb 14, 2020
Last Modified Date Jan 29, 2025 12:30 PM UTC
Pinout / Pin List Click Here (Member Only)

80HCPS1432CHMH Details

Manufacturer Part Number:
80HCPS1432CHMH
Manufacturer:
Renesas Electronics Corporation

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

80HCPS1432CHMH Overview

Use the download button to access the 80HCPS1432CHMH schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like 80HCP, or try a keyword search, such as Telecom Switching Circuits
