84329AV-01LFT - Renesas Electronics

84329AV-01LFT Details

• Manufacturer Part Number:

  84329AV-01LFT

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  PLCC

• Package Description:

  LCC-28

• Pin Count:

  28

• Manufacturer Package Code:

  PLG28

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• JESD-30 Code:

  S-PQCC-J28

• JESD-609 Code:

  e3

• Length:

  11.505 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  28

• Operating Temperature-Max:

  70 °C

• Output Clock Frequency-Max:

  700 MHz

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC28,.5SQ

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  260

• Primary Clock/Crystal Frequency-Nom:

  25 MHz

• Seated Height-Max:

  4.57 mm

• Supply Current-Max:

  110 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  TIN

• Terminal Form:

  J BEND

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  11.505 mm

• uPs/uCs/Peripheral ICs Type:

  CLOCK GENERATOR, OTHER
