844256DGLF - Renesas Electronics

Description: The 844256D is a Crystal-to-LVDS Clock Synthesizer/Fanout Buffer designed for SONET and Gigabit Ethernet applications. The output frequency can be set using the frequency select pins and a 25MHz crystal for Ethernet frequencies, or a 19.44MHz crystal for SONET. The low phase noise characteristics of the 844256D make it an ideal clock for these demanding applications.

Download 844256DGLF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
844256DGLF - Renesas Electronics PCB footprint - Small Outline Packages - Small Outline Packages - EJG24
click to zoom
3D Models
844256DGLF - Renesas Electronics  - 3D model - Small Outline Packages - EJG24
click to zoom

844256DGLF Details

  • Manufacturer Part Number:

    844256DGLF

  • Brand Name:

    Renesas

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    TSSOP

  • Pin Count:

    24

  • Manufacturer Package Code:

    EJG24

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Renesas Electronics Corporation

  • YTEOL:

    0

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    TIN

  • uPs/uCs/Peripheral ICs Type:

    CLOCK GENERATOR, OTHER

844256DGLF Frequently Asked Questions (FAQs)

  • Renesas provides a recommended PCB layout guide in their application note (APN) documents, which can be found on their website. The guide includes thermal vias, heat sink recommendations, and PCB layer stack-up suggestions to ensure optimal thermal performance.
  • Renesas recommends a specific power sequencing scheme to ensure proper device operation. This information can be found in the device's user manual or application notes. Typically, the sequence involves powering up the core voltage (VCC) before the input/output voltage (VIO).
  • Renesas recommends using high-quality, low-ESR decoupling capacitors with a value of 0.1 μF to 1 μF, placed as close as possible to the device's power pins. The exact capacitor values and placement can be found in the device's datasheet or application notes.
  • Renesas provides guidelines for clock signal integrity and jitter in their application notes. This includes recommendations for clock signal routing, termination, and filtering to minimize jitter and ensure reliable device operation.
  • Renesas provides thermal design guidelines and thermal models for the 844256DGLF in their datasheet and application notes. These resources help engineers design a thermal management system that can handle high-temperature environments, including heat sink selection, thermal interface materials, and airflow considerations.
