855-22-026-10-001101 - Mill-Max

Description: Spring-Loaded Pogo Pin Header Strip PCB Mount Spring-Loaded Header Vertical Mount Through-Hole

Download 855-22-026-10-001101 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
855-22-026-10-001101 - Mill-Max PCB footprint - Header, Vertical - Header, Vertical - 855-22-026-10-001101
click to zoom
3D Models
855-22-026-10-001101 - Mill-Max  - 3D model - Header, Vertical - 855-22-026-10-001101
click to zoom

855-22-026-10-001101 Details

  • Manufacturer Part Number:

    855-22-026-10-001101

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS AND REACH COMPLIANT

  • Country Of Origin:

    USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Manufacturer:

    Mill-Max Mfg Corp

  • YTEOL:

    9.15

  • Connector Type:

    BOARD CONNECTOR

  • Contact Finish Mating:

    NOT SPECIFIED

  • Contact Finish Termination:

    Gold (Au)

  • Contact Gender:

    MALE

  • Contact Material:

    NOT SPECIFIED

  • DIN Conformance:

    NO

  • Filter Feature:

    NO

  • IEC Conformance:

    NO

  • JESD-609 Code:

    e4

  • MIL Conformance:

    NO

  • Mating Information:

    MULTIPLE MATING PARTS AVAILABLE

  • Mixed Contacts:

    NO

  • Mounting Style:

    STRAIGHT

  • Mounting Type:

    BOARD

  • Number Of Connectors:

    ONE

  • Number of Rows Loaded:

    2

  • Option:

    GENERAL PURPOSE

  • Terminal Pitch:

    1.27 mm

  • Termination Type:

    SOLDER

  • Total Number of Contacts:

    26

  • UL Flammability Code:

    94V-0

855-22-026-10-001101 Frequently Asked Questions (FAQs)

  • The recommended torque for the screw terminals is typically between 0.5 to 1.5 in-lbs (0.056 to 0.169 Nm), but it's best to consult the manufacturer's application notes or contact their technical support for specific guidance.
  • Yes, the contacts are gold-plated, and the typical plating thickness is 0.000015 inches (0.38 microns) to 0.000030 inches (0.76 microns) per MIL-G-45204, but it's best to verify with the manufacturer for specific information.
  • The operating temperature range for the 855-22-026-10-001101 connector is typically -55°C to 125°C (-67°F to 257°F), but it's essential to check the datasheet or consult with the manufacturer for specific temperature ratings and any derating factors.
  • The 855-22-026-10-001101 connector is designed to meet the requirements of MIL-STD-202, Method 204, for vibration and shock, but it's crucial to evaluate the specific application requirements and consult with the manufacturer for guidance on using this connector in high-vibration or high-shock environments.
  • The 855-22-026-10-001101 connector is designed to meet the requirements of MIL-STD-202, Method 106, for humidity, but it's essential to evaluate the specific application requirements and consult with the manufacturer for guidance on using this connector in humid or wet environments.
