85727-1004 - Molex

85727-1004 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-0.7 Nm (4.4-6.3 in-lbs). It's essential to follow this torque specification to ensure reliable connections and prevent damage to the connector.
• Can I use this connector in high-vibration applications?
  Yes, the 85727-1004 connector is designed to withstand vibrations and can be used in high-vibration applications. However, it's crucial to ensure proper mounting and secure the connector to prevent damage or disconnection.
• Is this connector suitable for outdoor or harsh environmental use?
  The 85727-1004 connector has a rating of IP20, which means it provides some protection against solid objects and fingers, but it's not designed for outdoor or harsh environmental use. If you need a connector for outdoor use, consider using a connector with a higher IP rating or additional environmental protection.
• Can I use this connector with wire sizes other than AWG 20-24?
  While the datasheet specifies AWG 20-24 wire sizes, it's possible to use this connector with other wire sizes. However, you should verify the wire size and insulation diameter to ensure proper fit and connection reliability. Consult with Molex or a qualified engineer for guidance on using alternative wire sizes.
• How do I ensure reliable connections and prevent wire damage during assembly?
  To ensure reliable connections and prevent wire damage, follow proper assembly procedures, such as using the correct wire stripping length, applying the correct torque, and avoiding over-tightening or under-tightening the screw terminals. Additionally, use a wire gauge to verify the wire size and insulation diameter.
