8P34S2104-1NLGI - Renesas Electronics

8P34S2104-1NLGI Details

• Manufacturer Part Number:

  8P34S2104-1NLGI

• Part Life Cycle Code:

  Active

• Package Description:

  VFQFPN-40

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  8

• Additional Feature:

  ALSO OPERATES AT 2.5 V SUPPLY

• Family:

  8P34

• Input Conditioning:

  DIFFERENTIAL MUX

• JESD-30 Code:

  S-PQCC-N40

• Length:

  6 mm

• Logic IC Type:

  LOW SKEW CLOCK DRIVER

• Number of Functions:

  2

• Number of Terminals:

  40

• Number of True Outputs:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC40,.24SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TRAY

• Power Supply Current-Max (ICC):

  230 mA

• Prop. Delay@Nom-Sup:

  0.45 ns

• Propagation Delay (tpd):

  0.45 ns

• Same Edge Skew-Max (tskwd):

  0.04 ns

• Seated Height-Max:

  1 mm

• Supply Voltage-Max (Vsup):

  1.9 V

• Supply Voltage-Min (Vsup):

  1.71 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  6 mm
