Please enter a minimum 3 letters or numbers
Technical Content
Part Image

940C6P1K-F - Cornell Dubilier

Description: CORNELL DUBILIER - 940C6P1K-F - DC Film Capacitor, 0.1 µF, 600 V, Double Metallized PP, ± 10%, 940C Series

Download 940C6P1K-F Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
940C6P1K-F - Cornell Dubilier - PCB symbol
click to zoom
PCB Footprints
940C6P1K-F - Cornell Dubilier PCB footprint - Capacitors, Polarized Axial Diameter Horizontal Mounting - Capacitors, Polarized Axial Diameter Horizontal Mounting - 940C6P1K-F
click to zoom
3D Models
940C6P1K-F - Cornell Dubilier - 3D model - Capacitors, Polarized Axial Diameter Horizontal Mounting - 940C6P1K-F
click to zoom

940C6P1K-F Details

  • Manufacturer Part Number:

    940C6P1K-F

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    AXIAL LEADED

  • Reach Compliance Code:

    Compliant

  • ECCN Code:

    EAR99

  • HTS Code:

    8532.25.00.60

  • Manufacturer:

    Knowles CDE

  • YTEOL:

    7.24

  • Capacitance:

    0.1 µF

  • Capacitor Type:

    FILM CAPACITOR

  • Diameter:

    9 mm

  • Dielectric Material:

    POLYPROPYLENE

  • ESR:

    28 mΩ

  • JESD-609 Code:

    e3

  • Length:

    34 mm

  • Mounting Feature:

    THROUGH HOLE MOUNT

  • Negative Tolerance:

    10%

  • Number of Terminals:

    2

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Shape:

    TUBULAR PACKAGE

  • Package Style:

    Axial

  • Positive Tolerance:

    10%

  • Rated (AC) Voltage (URac):

    275 V

  • Rated (DC) Voltage (URdc):

    600 V

  • Ripple Current:

    2500 mA

  • Surface Mount:

    NO

  • Terminal Finish:

    Tin (Sn)

  • Terminal Shape:

    WIRE

940C6P1K-F Frequently Asked Questions (FAQs)

  • The recommended soldering temperature for the 940C6P1K-F is between 250°C to 260°C for a maximum of 5 seconds.
  • Yes, the 940C6P1K-F is a high-reliability capacitor that meets the requirements of MIL-PRF-123 and is suitable for use in high-reliability applications.
  • Yes, the 940C6P1K-F capacitor is designed to withstand high-vibration environments and meets the requirements of MIL-STD-202, Method 204.
  • The shelf life of the 940C6P1K-F capacitor is 2 years from the date of manufacture, as long as it is stored in its original packaging and under controlled humidity and temperature conditions.
  • Yes, the 940C6P1K-F capacitor is RoHS compliant and meets the requirements of the European Union's Restriction of Hazardous Substances (RoHS) directive.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

940C6P1K-F Overview

Use the download button to access the 940C6P1K-F schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 940C6, or try a keyword search, such as Film Capacitors

Parts related to 940C6P1K-F

Showing 0 results

Part Image

← Prev Next →
About Us Contact Us Terms of Service Do not sell or share my personal information Privacy Policy Digital Services Act Library Loader

All content Copyright © 2020, Supplyframe.com. All rights reserved. Back to top ↑

940C6P1K-F Alternates

Showing results

Image Part Number Model
Part Image 940H6P1K-F Knowles CDE

CAPACITOR, METALLIZED FILM
