94211AFLF - Renesas Electronics

94211AFLF Details

• Manufacturer Part Number:

  94211AFLF

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SSOP

• Package Description:

  0.300 INCH, ROHS COMPLIANT, MO-118, SSOP-48

• Pin Count:

  48

• Manufacturer Package Code:

  PVG48

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  ALSO REQUIRES 2.5V SUPPLY

• JESD-30 Code:

  R-PDSO-G48

• JESD-609 Code:

  e3

• Length:

  15.875 mm

• Moisture Sensitivity Level:

  1

• Number of Terminals:

  48

• Operating Temperature-Max:

  70 °C

• Output Clock Frequency-Max:

  150 MHz

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  260

• Primary Clock/Crystal Frequency-Nom:

  14.318 MHz

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.8 mm

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.635 mm

• Terminal Position:

  DUAL

• Width:

  7.5 mm

• uPs/uCs/Peripheral ICs Type:

  CLOCK GENERATOR, PROCESSOR SPECIFIC
