97ULP845AHILF - Renesas Electronics

97ULP845AHILF Details

• Manufacturer Part Number:

  97ULP845AHILF

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  CABGA

• Package Description:

  TSSOP-24

• Pin Count:

  28

• Manufacturer Package Code:

  ADG28

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Family:

  ULP

• Input Conditioning:

  DIFFERENTIAL

• JESD-30 Code:

  R-PBGA-B28

• JESD-609 Code:

  e1

• Length:

  4 mm

• Logic IC Type:

  PLL BASED CLOCK DRIVER

• Max I(ol):

  0.009 A

• Moisture Sensitivity Level:

  3

• Number of Functions:

  2

• Number of Terminals:

  28

• Number of True Outputs:

  5

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FBGA

• Package Equivalence Code:

  BGA28,5X6,25

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Same Edge Skew-Max (tskwd):

  0.05 ns

• Seated Height-Max:

  1 mm

• Supply Voltage-Max (Vsup):

  1.9 V

• Supply Voltage-Min (Vsup):

  1.7 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.635 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  4.5 mm

• fmax-Min:

  350 MHz
