9DBU0541AKILF - Renesas Electronics

Description: The 9DBU0541 is a member of IDT's 1.5 V Ultra-Low-Power (ULP) PCIe family. It has integrated terminations for direct connection to 100 ohm transmission lines. The device has 5 output enables for clock management, and 3 selectable SMBus addresses.

Download 9DBU0541AKILF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
9DBU0541AKILF - Renesas Electronics PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - NLG32P1---
click to zoom

9DBU0541AKILF Details

  • Manufacturer Part Number:

    9DBU0541AKILF

  • Brand Name:

    Renesas

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    VFQFPN

  • Pin Count:

    32

  • Manufacturer Package Code:

    NLG32P1

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Renesas Electronics Corporation

  • YTEOL:

    7

  • Logic IC Type:

    LOW SKEW CLOCK DRIVER

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn)

9DBU0541AKILF Frequently Asked Questions (FAQs)

  • Renesas provides a recommended PCB layout guide in their application notes (e.g., AN9834) and design guides (e.g., DG0034). It's essential to follow these guidelines to ensure optimal performance, minimize noise, and reduce EMI.
  • Renesas recommends a specific power sequencing scheme to ensure proper device operation. This information can be found in the device's datasheet, application notes, or design guides. Typically, it involves powering up the VCC and VCCIO pins in a specific order, followed by the clock and other signals.
  • The 9DBU0541AKILF has a thermal junction-to-case rating (RθJC) of 10°C/W. To ensure reliable operation, it's essential to implement proper thermal management, such as using a heat sink, thermal interface material, and ensuring good airflow. Renesas provides thermal design guidelines in their application notes and design guides.
  • To ensure proper clock signal integrity and minimize jitter, it's essential to follow Renesas' guidelines for clock signal routing, termination, and filtering. This information can be found in the device's datasheet, application notes, or design guides. Additionally, using a clock signal conditioner or jitter attenuator may be necessary in certain applications.
  • Renesas provides guidelines for minimizing EMI and RFI in their application notes and design guides. This includes using proper shielding, grounding, and routing techniques, as well as implementing EMI filters and shielding components. It's essential to follow these guidelines to ensure compliance with regulatory requirements and to minimize interference with other devices.
