A1325LLHLT-T - Allegro Microsystems

Description: Low Noise, Linear Hall-Effect Sensor IC With Analog Output

Download A1325LLHLT-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A1325LLHLT-T - Allegro Microsystems PCB footprint - SOT23 (3-Pin) - SOT23 (3-Pin) - A1325LLHLT-T
click to zoom
3D Models
A1325LLHLT-T - Allegro Microsystems  - 3D model - SOT23 (3-Pin) - A1325LLHLT-T
click to zoom

A1325LLHLT-T Details

  • Manufacturer Part Number:

    A1325LLHLT-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Reach Compliance Code:

    compliant

  • Manufacturer:

    Allegro MicroSystems LLC

  • Risk Rank:

    1.65

  • YTEOL:

    6.48

  • Body Breadth:

    1.91 mm

  • Body Height:

    1 mm

  • Body Length or Diameter:

    2.98 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    3

  • Operating Current-Max:

    9 mA

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Circuit Type:

    SINGLE-ENDED

  • Output Type:

    ANALOG VOLTAGE

  • Package Equivalence Code:

    TO-236

  • Package Shape/Style:

    RECTANGULAR

  • Resistance:

    1 Ω

  • Sensitivity (mV/G):

    3125 mV/G

  • Sensors/Transducers Type:

    MAGNETIC FIELD SENSOR,HALL EFFECT

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    4.5 V

  • Surface Mount:

    YES

  • Technology:

    BICMOS

  • Termination Type:

    SOLDER

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

A1325LLHLT-T Overview

Use the download button to access the A1325LLHLT-T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like A1325, or try a keyword search, such as Magnetic Field Sensors
