A1363LLUTR-1-T - Allegro Microsystems

Description: Low Noise, High Precision, Programmable Linear Hall-Effect Sensor IC

Download A1363LLUTR-1-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A1363LLUTR-1-T - Allegro Microsystems PCB footprint - Small Outline Packages - Small Outline Packages - LU, 8-Pin TSSOP
click to zoom
3D Models
A1363LLUTR-1-T - Allegro Microsystems  - 3D model - Small Outline Packages - LU, 8-Pin TSSOP
click to zoom

A1363LLUTR-1-T Details

  • Manufacturer Part Number:

    A1363LLUTR-1-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    TSSOP-8

  • Manufacturer:

    Allegro MicroSystems LLC

  • Terminal Finish:

    Tin (Sn)

A1363LLUTR-1-T Frequently Asked Questions (FAQs)

  • A good PCB layout should minimize noise and ensure proper grounding. Allegro recommends a 4-layer PCB with a solid ground plane, and keeping the sensitive analog signals away from the digital signals.
  • Calibration involves adjusting the zero-point and sensitivity of the sensor. Allegro provides a calibration procedure in the datasheet, which involves applying a known magnetic field and adjusting the output voltage accordingly.
  • The A1363LLUTR-1-T is rated for operation from -40°C to 150°C, but the optimal operating range is between -20°C to 85°C for best accuracy and reliability.
  • Yes, the A1363LLUTR-1-T is designed to withstand vibrations up to 10g, but it's essential to ensure proper mounting and mechanical stability to maintain accuracy and reliability.
  • To minimize EMI, use a shielded cable, keep the sensor away from high-frequency sources, and ensure proper grounding. Additionally, use a low-pass filter to reduce high-frequency noise.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

A1363LLUTR-1-T Overview

Use the download button to access the A1363LLUTR-1-T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like A1363, or try a keyword search, such as Other Sensors/Transducers
