A3922KLPTR-T - Allegro Microsystems

Description: Automotive Full Bridge MOSFET Drvr W/Asil Features

Download A3922KLPTR-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A3922KLPTR-T - Allegro Microsystems PCB footprint - Other - Other - LP_28-pin eTSSOP
click to zoom
3D Models
A3922KLPTR-T - Allegro Microsystems  - 3D model - Other - LP_28-pin eTSSOP
click to zoom

A3922KLPTR-T Details

  • Manufacturer Part Number:

    A3922KLPTR-T

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    TSSOP-28

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Allegro MicroSystems LLC

  • YTEOL:

    7.83

  • High Side Driver:

    YES

  • Input Characteristics:

    STANDARD

  • Interface IC Type:

    FULL BRIDGE BASED MOSFET DRIVER

  • JESD-30 Code:

    R-PDSO-G28

  • JESD-609 Code:

    e3

  • Length:

    9.7 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    28

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Peak Current Limit-Nom:

    0.001 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Equivalence Code:

    TSSOP28,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max:

    50 V

  • Supply Voltage-Min:

    6 V

  • Supply Voltage-Nom:

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Turn-off Time:

    1400 µs

  • Turn-on Time:

    13000 µs

  • Width:

    4.4 mm

A3922KLPTR-T Frequently Asked Questions (FAQs)

  • A good thermal design should be used to ensure the device operates within the recommended temperature range. A minimum of 2 oz copper thickness is recommended, and thermal vias should be used to dissipate heat. The device should be placed on a solid copper plane, and the PCB should have a good thermal conductivity.
  • The device requires a stable power supply with minimal noise and ripple. A decoupling capacitor of at least 10uF should be placed close to the device, and the power supply should be filtered to prevent noise and electromagnetic interference (EMI).
  • The device should be soldered using a reflow soldering process with a peak temperature of 260°C. The soldering process should be done in a nitrogen atmosphere to prevent oxidation. Hand soldering is not recommended.
  • Troubleshooting should start with verifying the power supply and checking for proper connections. The device's output should be checked for proper voltage and current. If issues persist, the device's internal diagnostics should be checked, and the application circuit should be reviewed for any design flaws.
  • The device should be stored in a dry, cool place away from direct sunlight. It should be handled with anti-static precautions, and the leads should not be bent or stressed. The device should be stored in its original packaging or an equivalent anti-static package.
