A4962KLPTR-T - Allegro Microsystems

Description: Automotive Sensorless BLDC MOSFET Gate Driver

Download A4962KLPTR-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A4962KLPTR-T - Allegro Microsystems PCB footprint - Other - Other - LP,20-Lead TSSOP
click to zoom
3D Models
A4962KLPTR-T - Allegro Microsystems  - 3D model - Other - LP,20-Lead TSSOP
click to zoom

A4962KLPTR-T Details

  • Manufacturer Part Number:

    A4962KLPTR-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Allegro MicroSystems LLC

  • YTEOL:

    0

  • Analog IC - Other Type:

    3-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G20

  • Length:

    6.5 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    50 V

  • Supply Voltage-Min (Vsup):

    4.2 V

  • Supply Voltage-Nom (Vsup):

    10 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    4.4 mm

A4962KLPTR-T Frequently Asked Questions (FAQs)

  • A good thermal design should be used to minimize thermal resistance. Allegro recommends a 2-layer or 4-layer PCB with a solid ground plane on the bottom layer, and a thermal relief pattern on the top layer to connect the device to the ground plane.
  • To ensure reliable operation in high-temperature environments, it is essential to follow proper thermal design guidelines, use a suitable thermal interface material, and ensure good airflow around the device. Additionally, the device should be operated within its specified temperature range.
  • Allegro recommends using a 10 μF ceramic capacitor and a 100 nF ceramic capacitor in parallel, placed as close as possible to the device's power pins. This helps to filter out noise and ensure stable operation.
  • To troubleshoot issues with the device's output current, check the input voltage, output voltage, and output current sense resistors. Verify that the device is properly configured and that the output current is within the specified range. Also, check for any signs of overheating or thermal shutdown.
  • Allegro recommends using a reflow soldering process with a peak temperature of 260°C (500°F) for a maximum of 20 seconds. Hand soldering is not recommended due to the device's small size and thermal sensitivity.
