A4990KLPTR-T - Allegro Microsystems

Description: Automotive Dual Full Bridge Driver

Download A4990KLPTR-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A4990KLPTR-T - Allegro Microsystems PCB footprint - Other - Other - LP,20-Lead TSSOP
click to zoom
3D Models
A4990KLPTR-T - Allegro Microsystems  - 3D model - Other - LP,20-Lead TSSOP
click to zoom

A4990KLPTR-T Details

  • Manufacturer Part Number:

    A4990KLPTR-T

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    4.40 X 6.50 MM, 1.20 MM HEIGHT, LEAD FREE, MO-153ACT, TSSOP-20

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Allegro MicroSystems LLC

  • Analog IC - Other Type:

    STEPPER MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G20

  • JESD-609 Code:

    e3

  • Length:

    6.5 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max (Vsup):

    28 V

  • Supply Voltage-Min (Vsup):

    7 V

  • Supply Voltage-Nom (Vsup):

    13.5 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    40

  • Width:

    4.4 mm

A4990KLPTR-T Frequently Asked Questions (FAQs)

  • A good PCB layout practice is to keep the high-current paths short and wide, and to use a solid ground plane to reduce EMI. It's also recommended to keep the device away from noise-sensitive components and to use shielding if necessary.
  • Proper thermal management can be achieved by providing a heat sink or a thermal pad on the device, and ensuring good airflow around the device. The device's thermal pad should be soldered to a copper plane on the PCB to dissipate heat efficiently.
  • The recommended input capacitor value is 10uF to 22uF, and a low-ESR ceramic capacitor (X5R or X7R dielectric) is recommended. The capacitor should be placed as close to the device's input pins as possible.
  • First, check the input voltage and current to ensure they are within the recommended range. Then, check the output voltage and current to ensure they are within the expected range. If the issue persists, check the PCB layout and component placement for any potential issues.
  • The A4990KLPTR-T is rated for operation up to 150°C, but it's recommended to derate the device's performance at high temperatures. Consult the datasheet for thermal derating information and ensure proper thermal management.
