AC3MBH2-AU-B - Amphenol

AC3MBH2-AU-B Details

• Manufacturer Part Number:

  AC3MBH2-AU-B

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  0

• Board Mounting Option:

  PEG

• Body Breadth:

  0.996 inch

• Body Depth:

  0.874 inch

• Body Length:

  0.996 inch

• Body/Shell Style:

  RECEPTACLE

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  XLR

• Contact Finish Mating:

  GOLD (3) OVER NICKEL (30)

• Contact Finish Termination:

  Gold (Au) - with Nickel (Ni) barrier

• Contact Gender:

  MALE

• Contact Material:

  BRASS

• Contact Style:

  RND PIN-SKT

• Durability:

  1500 Cycles

• JESD-609 Code:

  e4

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number of Poles:

  3

• Number of Ports:

  1

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED KEY

• Rated Current (Signal):

  6 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.138 inch

• Termination Type:

  SOLDER
