ACPL-3130-560E - Avago Technologies

Description: 2.5A Gate Driver Optical Coupling 3750Vrms 1 Channel 8-DIP Gull Wing

Download ACPL-3130-560E Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ACPL-3130-560E - Avago Technologies PCB footprint - Other - Other - 8-DIP
click to zoom

ACPL-3130-560E Details

  • Manufacturer Part Number:

    ACPL-3130-560E

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    0.300 INCH, ROHS COMPLIANT, SURFACE MOUNT, DIP-8

  • Reach Compliance Code:

    Compliant

  • HTS Code:

    8541.40.80.00

  • Manufacturer:

    Avago Technologies

  • YTEOL:

    7

  • Additional Feature:

    UL RECOGNIZED, VDE APPROVED

  • Configuration:

    COMPLEX

  • Forward Current-Max:

    0.016 A

  • Isolation Voltage-Max:

    3750 V

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Elements:

    1

  • Number of Functions:

    1

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    LOGIC IC OUTPUT OPTOCOUPLER

  • Power Dissipation-Max:

    0.25 W

  • Response Time-Nom:

    5e-7 ns

  • Supply Voltage-Min:

    15 V

  • Supply Voltage-Nom:

    30 V

  • Surface Mount:

    YES

  • Terminal Finish:

    TIN

ACPL-3130-560E Frequently Asked Questions (FAQs)

  • Broadcom recommends a PCB layout with a solid ground plane, minimal track length, and a 50-ohm transmission line for the output stage to ensure optimal performance and minimize electromagnetic interference (EMI).
  • To ensure reliable operation in high-temperature environments, it is recommended to follow proper thermal management practices, such as providing adequate heat sinking, using a thermally conductive PCB material, and keeping the device within its specified operating temperature range.
  • The maximum allowable voltage on the VCC pin is 5.5V. To protect against overvoltage, it is recommended to use a voltage regulator or a voltage clamp circuit to limit the voltage to within the specified range.
  • To troubleshoot issues with the ACPL-3130-560E, it is recommended to check the input signal quality, ensure proper power supply and ground connections, and verify that the device is operating within its specified temperature range. Additionally, using an oscilloscope to monitor the output signal and input signal can help identify the root cause of the issue.
  • While the ACPL-3130-560E is designed for isolated applications, it can be used in non-isolated applications with caution. However, this may compromise the device's electrical isolation and safety features, and may require additional circuitry to ensure safe operation.
