ACT212 - Panasonic

ACT212 Details

• Manufacturer Part Number:

  ACT212

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  5.53

• Body Breadth:

  14 mm

• Body Height:

  13.5 mm

• Body Length or Diameter:

  17.4 mm

• Coil Current(DC)-Max:

  0.067 A

• Coil Operate Voltage(DC):

  7.2 V

• Coil Power:

  800 mW

• Coil Release Voltage(DC):

  1 V

• Coil Resistance:

  180 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@14VDC

• Contact Voltage(DC)-Max:

  14 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  17.4mm x 14mm x 13.5mm

• Relay Action:

  MOMENTARY

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Sealing:

  EPOXY RESIN SEALED

• Surface Mount:

  NO

• Termination Type:

  SOLDER
