Qorvo provides a recommended PCB layout guide in their application note AN-114, which includes guidelines for thermal vias, copper pours, and component placement to ensure optimal thermal performance.
To optimize output voltage accuracy, ensure that the input voltage is within the recommended range, and the output voltage is set using the correct resistor divider ratio. Additionally, consider using a high-precision voltage reference and a low-noise power supply to minimize output voltage variations.
While the datasheet doesn't specify a maximum input voltage ripple, Qorvo recommends keeping the input voltage ripple below 100mV to ensure stable operation and minimize output voltage variations.
Yes, the ACT88430VM113-T is rated for operation up to 125°C. However, it's essential to ensure that the device is properly heatsinked and the PCB is designed to handle high temperatures. Consult Qorvo's thermal management guidelines for more information.
To troubleshoot output voltage errors or instability, check the input voltage, output voltage divider resistors, and the feedback loop. Ensure that the output voltage is within the specified range and that the device is not overheating. Consult Qorvo's application notes and technical support resources for more guidance.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ACT88430VM113-T Overview
Use the download button to access the ACT88430VM113-T schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like ACT88,
or try a keyword search, such as Power Management Circuits
About Qorvo
Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
