AD537SD - Rochester Electronics

AD537SD Details

• Manufacturer Part Number:

  AD537SD

• Pbfree Code:

  No

• Rohs Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  DIP

• Package Description:

  DIP,

• Pin Count:

  14

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• Additional Feature:

  IT CAN ALSO OPERATE FROM A +/-5V TO +/-18V SUPPLY

• Converter Type:

  VOLTAGE TO FREQUENCY CONVERTER

• JESD-30 Code:

  R-CDIP-T14

• JESD-609 Code:

  e0

• Length:

  19.43 mm

• Linearity Error-Max (EL):

  0.1%

• Moisture Sensitivity Level:

  NOT SPECIFIED

• Negative Input Voltage-Max:

  -18 V

• Number of Functions:

  1

• Number of Terminals:

  14

• Operating Frequency-Max:

  0.15 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Positive Input Voltage-Max:

  32 V

• Qualification Status:

  COMMERCIAL

• Seated Height-Max:

  5.08 mm

• Supply Voltage-Max:

  36 V

• Supply Voltage-Min:

  4.5 V

• Surface Mount:

  NO

• Temperature Grade:

  MILITARY

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  7.62 mm
