AD7383-4BCPZ-RL7 - Analog Devices

AD7383-4BCPZ-RL7 Details

• Manufacturer Part Number:

  AD7383-4BCPZ-RL7

• Brand Name:

  Analog Devices Inc

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  LFCSP:LEADFRM CHIP SCALE

• Package Description:

  LFCSP-24

• Pin Count:

  24

• Manufacturer Package Code:

  LFCSP:LEADFRM CHIP SCALE

• ECCN Code:

  3A991.c.4

• HTS Code:

  8542.39.00.30

• Date Of Intro:

  2023-05-08

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Analog Input Voltage-Max:

  1.7 V

• Analog Input Voltage-Min:

  -1.245 V

• Conversion Time-Max:

  0.25 µs

• Converter Type:

  ADC, SUCCESSIVE APPROXIMATION

• JESD-30 Code:

  S-XQCC-N24

• Length:

  4 mm

• Linearity Error-Max (EL):

  0.0057983%

• Moisture Sensitivity Level:

  3

• Number of Analog In Channels:

  4

• Number of Bits:

  16

• Number of Functions:

  1

• Number of Terminals:

  24

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  2'S COMPLEMENT BINARY

• Output Format:

  SERIAL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC24,.16SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Sample Rate:

  4 MHz

• Sample and Hold / Track and Hold:

  TRACK

• Seated Height-Max:

  0.6 mm

• Supply Current-Max:

  3.2 mA

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  4 mm
