AD9058ATJ/883B - Analog Devices

AD9058ATJ/883B Details

• Manufacturer Part Number:

  AD9058ATJ/883B

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFJ

• Package Description:

  CERAMIC, LCC-44

• Pin Count:

  44

• Manufacturer Package Code:

  J-44

• ECCN Code:

  3A001.a.2.c

• HTS Code:

  8542.39.00.30

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Analog Input Voltage-Max:

  2 V

• Converter Type:

  ADC, PROPRIETARY METHOD

• JESD-30 Code:

  S-CQCC-J44

• JESD-609 Code:

  e0

• Length:

  16.385 mm

• Linearity Error-Max (EL):

  0.49%

• Negative Supply Voltage-Nom:

  -5 V

• Number of Analog In Channels:

  2

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  44

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Bit Code:

  BINARY

• Output Format:

  PARALLEL, 8 BITS

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC44,.7SQ

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Qualification Status:

  Not Qualified

• Sample Rate:

  50 MHz

• Sample and Hold / Track and Hold:

  SAMPLE

• Screening Level:

  MIL-STD-883 Class B

• Seated Height-Max:

  3.43 mm

• Supply Current-Max:

  240 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Tin/Lead (Sn63Pb37)

• Terminal Form:

  J BEND

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Width:

  16.385 mm
