ADA4304-3ACPZ-R7 - Analog Devices

Description: RF Amplifier 1:3 SGL-Ended Active RF Splitter

Download ADA4304-3ACPZ-R7 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ADA4304-3ACPZ-R7 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
ADA4304-3ACPZ-R7 - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 16-Lead Lead Frame Chip Scale Package [LFCSP] 3 mm × 3 mm Body and 0.75 mm Package Height *
click to zoom
3D Models
ADA4304-3ACPZ-R7 - Analog Devices - 3D model - Quad Flat No-Lead - 16-Lead Lead Frame Chip Scale Package [LFCSP] 3 mm × 3 mm Body and 0.75 mm Package Height *
click to zoom

ADA4304-3ACPZ-R7 Details

  • Manufacturer Part Number:

    ADA4304-3ACPZ-R7

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    3 X 3 MM, ROHS COMPLIANT, LFCSP, 16 PIN

  • Pin Count:

    16

  • Manufacturer Package Code:

    CP-16-21

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Characteristic Impedance:

    75 Ω

  • Construction:

    COMPONENT

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    16

  • Operating Frequency-Max:

    865 MHz

  • Operating Frequency-Min:

    54 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    LCC16,.12SQ,20

  • Power Supplies:

    5 V

  • RF/Microwave Device Type:

    SPLITTER

  • Supply Current-Max:

    105 mA

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn)

ADA4304-3ACPZ-R7 Frequently Asked Questions (FAQs)

  • A good PCB layout for the ADA4304-3ACPZ-R7 involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing noise coupling between the input and output stages. It's also recommended to use a low-ESR capacitor for the power supply decoupling.
  • To ensure the ADA4304-3ACPZ-R7 is operating within its recommended operating conditions, verify that the supply voltage is within the specified range (2.7V to 5.5V), the operating temperature is within the specified range (-40°C to 125°C), and the input signals are within the specified voltage range.
  • The recommended input impedance for the ADA4304-3ACPZ-R7 is 1 kΩ or higher to ensure proper operation and to minimize the impact of input bias current on the input signal.
  • Yes, the ADA4304-3ACPZ-R7 is rated for operation up to 125°C, making it suitable for high-temperature environments. However, it's essential to ensure that the device is properly cooled and that the operating conditions are within the specified range.
  • To troubleshoot issues with the ADA4304-3ACPZ-R7, start by verifying the power supply voltage, checking for proper input signal levels, and ensuring that the device is properly configured. Use an oscilloscope to monitor the input and output signals, and consult the datasheet and application notes for guidance.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ADA4304-3ACPZ-R7 Overview

Use the download button to access the ADA4304-3ACPZ-R7 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADA43, or try a keyword search, such as RF/Microwave Splitter/Combiners

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
