ADC-321 - DATEL

ADC-321 Details

• Manufacturer Part Number:

  ADC-321

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  QFP

• Package Description:

  PLASTIC, QFP-32

• Pin Count:

  32

• HTS Code:

  8542.39.00.30

• Manufacturer:

  DATEL Inc

• Analog Input Voltage-Max:

  2.5 V

• Analog Input Voltage-Min:

  0.5 V

• Converter Type:

  ADC, FLASH METHOD

• JESD-30 Code:

  S-PQFP-G32

• JESD-609 Code:

  e0

• Length:

  7 mm

• Linearity Error-Max (EL):

  0.5859%

• Number of Analog In Channels:

  1

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  32

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY

• Output Format:

  PARALLEL, 8 BITS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QFP

• Package Equivalence Code:

  TQFP32,.35SQ,32

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK

• Qualification Status:

  Not Qualified

• Sample Rate:

  100 MHz

• Sample and Hold / Track and Hold:

  SAMPLE

• Seated Height-Max:

  1.85 mm

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
