ADE-5+ - Mini-Circuits

Description: RF Mixer DBL BAL MIX / SURF MT / RoHS

Download ADE-5+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ADE-5+ - Mini-Circuits PCB footprint - Other - Other - ADE-5+-2
click to zoom
3D Models
ADE-5+ - Mini-Circuits  - 3D model - Other - ADE-5+-2
click to zoom

ADE-5+ Details

  • Manufacturer Part Number:

    ADE-5+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6

  • Construction:

    COMPONENT

  • Conversion Loss-Max:

    9.3 dB

  • Input Power-Max (CW):

    17 dBm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    1500 MHz

  • Operating Frequency-Min:

    5 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    FL6,.2,100

  • RF/Microwave Device Type:

    DOUBLE BALANCED

  • Surface Mount:

    YES

  • VSWR-Max:

    2.96

ADE-5+ Frequently Asked Questions (FAQs)

  • A good grounding scheme is crucial for the ADE-5+. It's recommended to use a solid ground plane on the PCB, and to connect the device's ground pins to the ground plane using vias. Additionally, keep the signal traces as short as possible and use a 50-ohm impedance-controlled layout to minimize reflections.
  • The ADE-5+ requires a bias voltage of 5V and a bias current of around 100mA. To optimize the biasing, ensure that the voltage regulator is stable and has low noise, and use a low-ESR capacitor for decoupling. Also, consider using a bias-T or a DC block to isolate the DC bias from the RF signal.
  • The ADE-5+ can handle up to 1W of input power. To protect it from overdrive, use an attenuator or a limiter to reduce the input power, and consider adding a voltage-controlled attenuator to dynamically adjust the input power. Also, ensure that the input signal is properly matched to the device's 50-ohm input impedance.
  • To calibrate the ADE-5+, use a calibration kit or a vector network analyzer to measure the device's S-parameters. Then, use the measured data to calculate the amplitude and phase corrections. It's also recommended to perform a system calibration using a known reference signal to ensure accurate measurements.
  • The ADE-5+ operates from -40°C to 85°C. Temperature affects the device's performance, particularly the amplitude and phase accuracy. Ensure that the device is operated within the specified temperature range, and consider using temperature compensation techniques to minimize the effects of temperature drift.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ADE-5+ Overview

Use the download button to access the ADE-5+ schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADE-5, or try a keyword search, such as RF/Microwave Mixers

About Mini-Circuits

Mini-Circuits is a global leader in the design, manufacturing, and distribution of RF and microwave components and systems. The company's product portfolio includes a vast array of components such as amplifiers, mixers, splitters, couplers, filters, switches, and attenuators, among others. These components cover frequency ranges from DC to 65 GHz and beyond, serving applications in wireless communication, satellite communication, radar systems, test and measurement equipment, medical devices, and more.

Parts related to ADE-5+

Showing 0 results

ADE-5+ Alternates

Showing results

Image Part Number Model
Part Image ADE-5 Mini-Circuits

Double Balanced Mixer, 5MHz Min, 1500MHz Max, 9.3dB Conversion Loss-Max
