ADIP-40-Z-LC - ASSMANN WSW components GmbH

ADIP-40-Z-LC Details

• Manufacturer Part Number:

  ADIP-40-Z-LC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  ASSMANN WSW components GmbH

• YTEOL:

  8

• Additional Feature:

  SOLDERED DIRECTLY TO THE BOARD

• Body Breadth:

  0.717 inch

• Body Depth:

  0.232 inch

• Body Length:

  2.207 inch

• Connector Type:

  BOARD CONNECTOR

• Contact Design:

  PREASSEM CONN

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  30 mΩ

• Contact Style:

  IDC

• Dielectric Withstanding Voltage:

  500AC/DC V

• Filter Feature:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• Mating Contact Pitch:

  0.1 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Type:

  CABLE

• Number Of Connectors:

  ONE

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Packing Method:

  TRAY

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL

• Terminal Length:

  0.129 inch

• Termination Type:

  IDC

• Total Number of Contacts:

  40

• UL Flammability Code:

  94V-0

• Wire Size-Max:

  26 AWG

• Wire Size-Min:

  30 AWG
