ADQ-90+ - Mini-Circuits

Description: Signal Conditioning PWR SPLTR CMBD / SURF MT/ RoHS

Download ADQ-90+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ADQ-90+ - Mini-Circuits PCB footprint - Other - Other - CJ725-2021-1
click to zoom
3D Models
ADQ-90+ - Mini-Circuits  - 3D model - Other - CJ725-2021-1
click to zoom

ADQ-90+ Details

  • Manufacturer Part Number:

    ADQ-90+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6

  • Additional Feature:

    ISOLATION-MIN (DB):20

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    26.99 dBm

  • Insertion Loss-Max:

    0.7 dB

  • JESD-609 Code:

    e3

  • Operating Frequency-Max:

    90 MHz

  • Operating Frequency-Min:

    55 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    SPLITTER AND COMBINER

  • Terminal Finish:

    TIN OVER NICKEL

  • VSWR-Max:

    1.16
