ADSP-BF516KSWZ-3 - Analog Devices

Description: Blackfin Embedded Processor

Download ADSP-BF516KSWZ-3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ADSP-BF516KSWZ-3 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
ADSP-BF516KSWZ-3 - Analog Devices PCB footprint - Quad Flat Packages - Quad Flat Packages - 176-Lead Low Profile Quad Flat Package [LQFP_EP] (SQ-176-2)
click to zoom
3D Models
ADSP-BF516KSWZ-3 - Analog Devices - 3D model - Quad Flat Packages - 176-Lead Low Profile Quad Flat Package [LQFP_EP] (SQ-176-2)
click to zoom

ADSP-BF516KSWZ-3 Details

  • Manufacturer Part Number:

    ADSP-BF516KSWZ-3

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    QFP

  • Package Description:

    LQFP-176

  • Pin Count:

    176

  • Manufacturer Package Code:

    SQ-176-2

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    3A991.A.2

  • HTS Code:

    8542.31.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Address Bus Width:

    19

  • Barrel Shifter:

    YES

  • Bit Size:

    32

  • Boundary Scan:

    YES

  • Clock Frequency-Max:

    300 MHz

  • External Data Bus Width:

    16

  • Format:

    FIXED POINT

  • Internal Bus Architecture:

    MULTIPLE

  • JESD-30 Code:

    S-PQFP-G176

  • Length:

    24 mm

  • Low Power Mode:

    YES

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    176

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LFQFP

  • Package Equivalence Code:

    QFP176,1.0SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    FLATPACK, LOW PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.6 mm

  • Speed:

    300 MHz

  • Supply Voltage-Max:

    1.47 V

  • Supply Voltage-Min:

    1.164 V

  • Supply Voltage-Nom:

    1.225 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    24 mm

  • uPs/uCs/Peripheral ICs Type:

    DIGITAL SIGNAL PROCESSOR, OTHER

ADSP-BF516KSWZ-3 Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for the ADSP-BF516KSWZ-3 is -40°C to 85°C. However, it's essential to note that the device can operate at temperatures beyond this range, but with reduced performance and reliability.
  • To optimize power consumption, you can use the device's power-saving features such as dynamic voltage and frequency scaling, clock gating, and power-down modes. Additionally, optimizing your code to minimize CPU usage, using low-power peripherals, and reducing memory access can also help.
  • The ADSP-BF516KSWZ-3 supports a maximum clock frequency of 400 MHz. However, the actual clock frequency may vary depending on the specific application, operating conditions, and power consumption requirements.
  • While the ADSP-BF516KSWZ-3 is a reliable device, it is not specifically designed for safety-critical applications. If you need to use the device in a safety-critical application, you should consult with Analog Devices Inc. and ensure that the device meets the required safety standards and regulations.
  • To ensure EMC, you should follow proper PCB design practices, use shielding and filtering, and ensure that the device is properly grounded. Additionally, you should comply with relevant EMC standards and regulations, such as FCC and CE.

Trust Checks

This model has been verified by system checks.
System Verified
Sponsored

ADSP-BF516KSWZ-3 Overview

Use the download button to access the ADSP-BF516KSWZ-3 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADSP-, or try a keyword search, such as Digital Signal Processors

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
