ADSP-SC589KBCZ-5B Frequently Asked Questions (FAQs)

• What is the recommended power-up sequence for the ADSP-SC589?
  The recommended power-up sequence is to apply VDDINT and VDDRTC first, followed by VDDDDR. This ensures that the internal voltage regulators are powered up correctly.
• How do I configure the external memory interface (EMIF) for the ADSP-SC589?
  The EMIF can be configured using the Memory Controller (MC) registers. The MC registers control the memory timing, width, and type. Refer to the ADSP-SC589 Hardware Reference Manual for more information.
• What is the maximum frequency of the core and how do I change it?
  The maximum frequency of the core is 450 MHz. The core frequency can be changed by modifying the Clock Generation Unit (CGU) registers. The CGU generates the clock signals for the core and peripherals.
• How do I use the DMA controller on the ADSP-SC589?
  The DMA controller can be used to transfer data between peripherals and memory. The DMA controller is configured using the DMA registers. The DMA request signals are generated by the peripherals and the DMA controller transfers the data accordingly.
• What is the purpose of the PLLs on the ADSP-SC589?
  The PLLs (Phase-Locked Loops) on the ADSP-SC589 are used to generate the clock signals for the core, peripherals, and external interfaces. The PLLs can be configured to generate different clock frequencies.
