ADTT1-1 - Mini-Circuits

Description: 0.3 MHz - 300 MHz RF TRANSFORMER

Download ADTT1-1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ADTT1-1 - Mini-Circuits PCB footprint - Other - Other - ADTT1-1-2
click to zoom
3D Models
ADTT1-1 - Mini-Circuits  - 3D model - Other - ADTT1-1-2
click to zoom

ADTT1-1 Details

  • Manufacturer Part Number:

    ADTT1-1

  • Pbfree Code:

    No

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    0

  • Application:

    MATCHING

  • Cut-off Frequency-Max:

    300 MHz

  • Cut-off Frequency-Min:

    0.3 MHz

  • DC Unbalance Current-Max:

    30 mA

  • Height:

    2.84 mm

  • Insertion Loss:

    3 dB

  • JESD-609 Code:

    e0

  • Length:

    7.87 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Primary Winding:

    1

  • Number of Secondary Winding:

    1

  • Operating Frequency-Max:

    300000 kHz

  • Operating Frequency-Min:

    300 kHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -20 °C

  • Power Rating:

    0.25 W

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Transformer Type:

    RF TRANSFORMER

  • Width:

    5.59 mm

ADTT1-1 Frequently Asked Questions (FAQs)

  • Mini-Circuits provides a recommended PCB layout and footprint for the ADTT1-1 in their application notes. It's essential to follow these guidelines to ensure optimal performance and minimize parasitic effects.
  • The ADTT1-1 has a nominal impedance of 50 ohms. To impedance match, use a pi-network or a T-network topology with resistors and capacitors. Mini-Circuits provides a matching network design guide in their application notes.
  • The ADTT1-1 can handle up to 1 watt of continuous power. However, it's essential to derate the power handling based on the operating frequency, temperature, and other environmental factors to ensure reliable operation.
  • Yes, the ADTT1-1 can be used in switching applications, but it's crucial to ensure that the switching frequency is within the device's bandwidth and that the voltage and current ratings are not exceeded.
  • Common issues with the ADTT1-1 include overheating, mismatch, and damage from electrostatic discharge. To troubleshoot, check the PCB layout, impedance matching, and handling procedures. Consult the datasheet and application notes for guidance.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ADTT1-1 Overview

Use the download button to access the ADTT1-1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADTT1, or try a keyword search, such as RF Transformers

About Mini-Circuits

Mini-Circuits is a global leader in the design, manufacturing, and distribution of RF and microwave components and systems. The company's product portfolio includes a vast array of components such as amplifiers, mixers, splitters, couplers, filters, switches, and attenuators, among others. These components cover frequency ranges from DC to 65 GHz and beyond, serving applications in wireless communication, satellite communication, radar systems, test and measurement equipment, medical devices, and more.
