ADUCM300WBCPZ - Analog Devices

ADUCM300WBCPZ Details

• Manufacturer Part Number:

  ADUCM300WBCPZ

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LFCSP-32

• Pin Count:

  32

• Manufacturer Package Code:

  CP-32-15

• ECCN Code:

  EAR99

• HTS Code:

  8542.31.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Analog Input Voltage-Max:

  3 V

• Analog Input Voltage-Min:

  -3 V

• Converter Type:

  ADC, FLASH METHOD

• JESD-30 Code:

  S-PQCC-N32

• Length:

  6 mm

• Linearity Error-Max (EL):

  0.02%

• Number of Analog In Channels:

  2

• Number of Bits:

  20

• Number of Functions:

  1

• Number of Terminals:

  32

• Operating Temperature-Max:

  115 °C

• Operating Temperature-Min:

  -40 °C

• Output Bit Code:

  BINARY

• Output Format:

  SERIAL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC32,.2SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Sample Rate:

  8000 MHz

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  7 mA

• Supply Voltage-Nom:

  7 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  6 mm
