ADXL001-250BEZ-R7 - Analog Devices

Description: Accelerometers High Performance Wide Bandwidth

Download ADXL001-250BEZ-R7 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ADXL001-250BEZ-R7 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
ADXL001-250BEZ-R7 - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - ADXL001-250BEZ-R7
click to zoom
3D Models
ADXL001-250BEZ-R7 - Analog Devices - 3D model - Quad Flat No-Lead - ADXL001-250BEZ-R7
click to zoom

ADXL001-250BEZ-R7 Details

  • Manufacturer Part Number:

    ADXL001-250BEZ-R7

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    LCC

  • Package Description:

    LCC-8

  • Pin Count:

    8

  • Manufacturer Package Code:

    E-8-1

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-CQCC-N8

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    CERAMIC, METAL-SEALED COFIRED

  • Package Code:

    QCCN

  • Package Equivalence Code:

    LCC8,.2SQ

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    2.38 mm

  • Supply Voltage-Max (Vsup):

    6 V

  • Supply Voltage-Min (Vsup):

    3.135 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    QUAD

  • Width:

    5 mm

ADXL001-250BEZ-R7 Frequently Asked Questions (FAQs)

  • The recommended PCB layout and land pattern for the ADXL001-250BEZ-R7 can be found in the ADXL001 Evaluation Board documentation, which provides a reference design for proper component placement and routing.
  • Calibration of the ADXL001-250BEZ-R7 involves applying a known acceleration to the device and adjusting the sensitivity and offset registers to achieve the desired output. A detailed calibration procedure can be found in the ADXL001 datasheet and application notes.
  • The ADXL001-250BEZ-R7 can measure accelerations up to ±250g, but it's recommended to operate within the specified range of ±200g for optimal performance and accuracy.
  • The ADXL001-250BEZ-R7 has a digital SPI interface that can be connected to a microcontroller or FPGA. The device requires a 3.3V or 5V power supply, and the interface signals should be level-shifted accordingly. A detailed interface description can be found in the ADXL001 datasheet.
  • The ADXL001-250BEZ-R7 has a typical power consumption of 3.5mA at 3.3V and 5.5mA at 5V, depending on the operating mode and output data rate. A detailed power consumption breakdown can be found in the ADXL001 datasheet.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ADXL001-250BEZ-R7 Overview

Use the download button to access the ADXL001-250BEZ-R7 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADXL0, or try a keyword search, such as Other Signal Circuits

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
