AGIC040R39A1I1VB - Intel

AGIC040R39A1I1VB Details

• Manufacturer Part Number:

  AGIC040R39A1I1VB

• Part Life Cycle Code:

  Transferred

• Package Description:

  FBGA-3948

• HTS Code:

  8542.31.00.60

• Manufacturer:

  Intel Corporation

• YTEOL:

  6

• JESD-30 Code:

  S-PBGA-B3948

• Length:

  56 mm

• Number of CLBs:

  137200

• Number of Inputs:

  576

• Number of Logic Cells:

  4047400

• Number of Outputs:

  576

• Number of Terminals:

  3948

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  137200 CLBS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  4.168 mm

• Surface Mount:

  YES

• Technology:

  10 nm

• Terminal Form:

  BALL

• Terminal Pitch:

  0.92 mm

• Terminal Position:

  BOTTOM

• Width:

  56 mm
